Easy to Operate High Quality Stacker Standing on Hyder 2t Electric

Overview

Basic Info.

Model NO.	HTB20S
Fuel	Electric
Load center	>500mm
Lift height	5.5m
Condition	New
Drive Motor	AC Motor
Model	Htb20s
Lift Motor	DC Motor
Lifting Height	3000-5500
Application	Warehouse
Product Name	Standing on Stacker/Standing on Jack/Truck
Transport Package	Sea-Worthy Packing for Exporting
Specification	2110X850X2070MM
Trademark	HYDER
Origin	China
HS Code	84271090
Production Capacity	3000 Sets/Year

Product Description

Easy To Operate High Quality Stacker Standing On HYDER 2T Electric

Product Description

The electric pallet truck uses the battery as the power source, the motor as the power, and drives the vehicle to walk through the gear transmission. The lifting of the fork depends on the DC motor and hydraulic transmission, and the oil cylinder moves up and down to lift the fork and the goods. It has the characteristics of labor saving, high efficiency, smooth operation of goods, simple operation, safety and reliability, low noise and no pollution. The forklift uses a 48-volt large-capacity battery, which greatly prolongs the use time after one charge.

Product Parameters

Standing - on Stacker
1	Manufacturer		HYDER
2	Model		HTB20-SA		HTB20-SB		HTB20-SA	HTB20-SA
3	Power type		Battery		Battery		Battery	Battery
4	Rated load capacity	kg	2000		2000		1500	2000
5	Load center	mm	500		500		500	500
6	Operate type		Standing on		Standing on		Standing on	Standing on
7	Total length	mm	860		860		860	860
8	Mast closed height	mm	2080		2080		2080	2080
9	Lift height	mm	3000		3000		3000	3000
10	Mast extended height	mm	3500		3500		3500	3500
11	Min working aisle width	mm	2500		2500		2500	2500
12	Fork mini ground clearance	mm	85		85		85	85
13	Min turning radius	mm	1612		1612		1612	1612
14	Fork size(L*W*H)	mm	1150*180*55		1150*180*55		1100*170*55	1100*170*55
15	Max lifting speed (no load)	mm/s	100		100		100	100
16	Max lifting speed (full load)	mm/s	560		560
17	Max driving speed (no load)	km/h	5.5		5.5		5.5	5.5
18	Max driving speed (full load)	km/h	4.5		5.5		4.5	4.5
19	Max gradeability(full /noload)	%	5.0/7.0		5.0/7.0		3.0/5.0	3.0/5.0
20	Driving motor	kw	AC2.0(vertical)		AC1.5(horizontal type)		DC0.75	AC1.5
21	Lifting motor	kw	2.2		2.2		DC2.2	2.2
22	Total weight	kg	1250		1150		730	750
23	Battery capacity	V/AH	24V/210AH		24V/210AH		24V/100AH	24V/160AH
24	Chager	V/A	24V/25A		24V/25A		24V/18A	24V/18A
25	Mast protection		Yes(Acrylic)		Yes(Metal)		Yes(Metal)	Yes(Metal)
26	Bearing wheel size(front)	mm	80X70		80X70		80X70	80X70
27	Balance wheel size(black)	mm	125X50		125X50		125X50	125X50
28	Service Brake		Electric magnetic		Electric magnetic		Electric magnetic	Electric magnetic
29	Steering type		EPS		Mechanical		Mechanical	Mechanical
30	Working hours	h/cycles	6-8		6-8		4.5/80	4.5/80
31	Mast steel	Hrs	H shaped steel		H shaped steel		C shaped steel	C+H shaped steel

Detailed Photos

*Energy -saving design*24V electrical system for different use* Cost-effective deign with AC Motor*EPS function optional*Fingertip control of all functions*Direction reverse switch on handle*Emergency Power disconnect* Complete steel cover and side guards

Packaging & Shipping

Related Products

Self Lifting Stacker

Electric Stacker

Company Profile

Shaanxi Hyder Intelligent Machinery Co., Ltd ,The head office of HYDER Intelligent Machinery in Yanta district, Xi'an city, our engineer team all have more than 17 years working experience in the fields of forklift. Professional international sale and after sales service team can offer you quick response and effective service. HYDER has built long and stable cooperation with many well-known domestic and oversea enterprises and our products have passed the CE, BV, ISO and third-party detection institution test and certificate. HYDER owns a high efficient team and complete QC system and offers qualified products for the customers in more than 40 countries where the sales network has built.
Shaanxi hyder Intelligent Machinery Co., Ltd. is committed to becoming a high-end intelligent storage and logistics equipment recognized and trusted by the world. We build our national brand with advanced technology, mainly engaged in global warehousing and logistics business.
Our products are Pallet truck series, Stacker series and Electric forklift series. By repeatedly testing in the market and adopting customer feedback, while reducing costs, we are committed to every small function, improving work efficiency, reducing employee operation safety risks, and improving customer use efficiency.

Certifications

FAQ

Q1: Are you a manufacturer or trading company?
A1: We are a manufacturer, and we have our own factory and trading company ,offices brancheds located in Shanghai,Anhui,Shannxi.
Q2: How is Your Price Compare With Other Factories?A2: We are professional forklift manufacturers with more than 12 years produce and export experience we can sure to provide you more competitive price than other factories.
Q3: Can you guarantee your products?
A3: Yes, we guarantee your 100% satisfaction on all our products.
Please feel free to back to us immediately if you are not satisfied with our quality or service. If the product does not meet the contract requirements, we will send you a free replacement or give you compensation in the next order.
Q4: Do you offer custom design?
A4: Custom design is surely available. We have very rich experience in customizing shelves.
Q5: Can you manufacture the forklift as per my requirement?
A5: Yes, these items have other options: lifting height, tires, cabin,lights, fork length, colors,controller, engine, battery, charging voltage.etc
